BRAND : UNI-T
ITEM NO.: UTI720A
ORIGIN : CHINA
IR RESOLUTION : 256×192
DISPLAY : 2.8" IPS (320×240)
FRAME RATE : ≤25HZ
TEMPERATURE RANGE : -20℃~400℃ (-4°F~752°F)
THERMAL SENSITIVITY(NETD) : ≤50MK
PIXEL SIZE : 12µM
LENS FOCAL LENGTH : 3.2MM
DISPLAY : 2.8” TFT LCD (320×240)
FIELD OF VIEW(FOV) : 56°×42.2°
THERMAL SENSITIVITY(NETD) : ≤50MK
SPATIAL RESOLUTION(IFOV) : 3.8MRAD
SPECTRAL RANGE : 8~14µM
FOCUS : FOCUS FREE
TEMPERATURE MEASUREMENT RANGE : -20℃~400℃ (-4℉~752℉)
ACCURACY : ±2℃ OR ±2% WHICHEVER IS GREATER
EMISSIVITY : 0.01~1.00 ADJUSTABLE (0.95 DEFAULT)
FUNCTIONS :
IMAGE MODES : THERMAL
ON SCREEN ANALYZER : 3 POINTS
HI/LO TEMPERATURE ALARM : V(LED FLASHLIGHT, ICON ANIMATION)
LED LIGHTING : YES
PC SOFTWARE : PC SCREEN PROJECTION, REAL-TIME IMAGE TRANSMISSION, PHOTO DOWNLOAD & ANALYSIS
GENERAL CHARACTERISTICS :
USB : USB TYPE-C
BATTERY : FIXED LI-ION BATTERY (3.6V 5000MAH)
BATTERY OPERATING TIME : ≥7 HOURS
BATTERY CHARGING TIME : ≤5 HOURS
STORAGE : 32GB SD CARD
IP RATING : IP65
DROP PROOF : 2M
CERTIFICATES : CE, FCC, ROHS
LANGUAGES : EN, FR, DE, IT, ES, SV
. IR RESOLUTION
. PC ANALYSIS SOFTWARE
. LED LIGHTING
. IP RATING
. 2M DROP PROOF
UTI720A IS A FEATURED THERMAL IMAGER WITH A QUALITY BUILD. COOPERATE WITH 2.8" LARGE DISPLAY SCREEN, UTI720A'S HIGH-DEFINITION IR RESOLUTION ASSISTS USERS TO NOTICE THERMAL ABNORMALITIES EASILY. FURTHERMORE, IT IS ALSO EQUIPPED WITH HIGH BRIGHTNESS LED LIGHT. THIS RUGGED PRODUCT HAS IP65 CERTIFICATE AND WITHSTAND 2 METER DROP.
| Item Code | UNITUTI720A |
|---|---|
| Barcode | 6935750572054 |
| Brand | UNI-T |
The UNI-T UTI720A Professional Heavy Duty Thermal Imager is a rugged and reliable thermal imaging camera designed to help professionals quickly identify temperature variations and thermal abnormalities. With a high-definition infrared imaging system and a large 2.8-inch display, it provides clear thermal visualization for inspection, troubleshooting, maintenance, and diagnostic applications.
Built for demanding working environments, the UTI720A combines thermal imaging, temperature measurement, LED lighting, PC analysis software, IP65 protection, and 2-meter drop resistance in a durable handheld design.
The UNI-T UTI720A is used to detect and visualize heat patterns that may not be visible to the naked eye. It helps users identify abnormal temperature areas, making it useful for preventive maintenance, electrical inspection, mechanical troubleshooting, HVAC diagnostics, building inspection, and industrial equipment checks.
By viewing temperature differences as a thermal image, technicians can locate potential problems quickly without relying only on physical inspection.
Safety note: Thermal imaging helps identify temperature patterns but does not replace appropriate electrical, mechanical, or safety procedures. Always follow the relevant equipment manufacturer's safety instructions when inspecting live or hazardous equipment.
The UNI-T UTI720A is a strong choice for professionals who need a durable thermal imaging tool for routine inspection and troubleshooting. Its combination of high-definition infrared imaging, temperature measurement, a large display, built-in LED lighting, and PC analysis capabilities makes it suitable for both field inspections and detailed follow-up analysis.
The rugged construction is another important advantage. With IP65 protection and 2-meter drop resistance, the UTI720A is designed to handle demanding workshop, maintenance, and field environments better than a basic thermal imaging device.
The UNI-T UTI720A is suitable for professionals and technicians who regularly need to identify temperature differences or thermal abnormalities.
The UNI-T UTI720A Thermal Imager can be used across a wide range of professional inspection environments, including industrial facilities, electrical workshops, mechanical workshops, HVAC service locations, automotive workshops, commercial buildings, maintenance departments, and field service applications.
Thermal imaging provides technicians with a visual way to understand temperature distribution across a surface or component. The UNI-T UTI720A combines this capability with a rugged handheld design, large display, LED lighting, and PC connectivity, making it a practical tool for professional inspection and maintenance work.
Whether used for electrical troubleshooting, equipment maintenance, HVAC inspection, mechanical checks, or industrial diagnostics, the UTI720A helps users quickly visualize thermal conditions and identify areas that may require further investigation.
The UNI-T UTI720A is used for thermal inspection and temperature measurement. It helps professionals visualize heat patterns and identify thermal abnormalities in electrical, mechanical, HVAC, automotive, building, and industrial applications.
Yes. The UTI720A is designed as a professional heavy-duty thermal imager with rugged construction, IP65 protection, drop resistance, thermal analysis functions, and PC software support.
Yes. The UNI-T UTI720A includes built-in LED lighting to provide additional illumination when performing inspections in darker areas.
Yes. The UTI720A supports PC connectivity and software functions including screen projection, real-time image transmission, photo download, and thermal image analysis.
Yes. The UTI720A is designed for demanding professional environments and features IP65 protection and resistance to drops from up to 2 meters.
A thermal imager detects and displays infrared temperature differences across surfaces and objects. This can help users identify unusual hot or cold areas that may require further inspection or troubleshooting.
Yes. The UTI720A can assist qualified technicians with electrical inspection by visualizing temperature differences around suitable electrical components and equipment.
Yes. The UTI720A can be used as a thermal inspection tool for HVAC service and maintenance applications where identifying temperature variations is useful.
The UTI720A provides three on-screen temperature analysis points for examining specific areas within the thermal image.
Choose the UNI-T UTI720A Professional Heavy Duty Thermal Imager for reliable thermal inspection, troubleshooting, and maintenance applications. Its high-definition thermal imaging, large display, built-in LED lighting, PC analysis capability, and rugged construction make it a practical choice for professional technicians and maintenance teams.
