UNI-T LONG-DISTANCE THERMAL MONOCULAR WITH LASER RANGE UTX325MR | 400×300 PIXELS FOR DETAILED THERMAL IMAGING | 25MM FOR LONG-RANGE PERFORMANCE | ≤25MK FOR SUPERIOR DETECTION ACCURACY | 10.5° × 7.9° FOR PRECISE SCANNING

UNI-T UTX325MR Long-Distance Thermal Monocular with Laser Range Finder

The UNI-T UTX325MR Long-Distance Thermal Monocular is a professional thermal imaging device designed for long-range observation, heat detection, and accurate distance measurement. Combining a 400 × 300 pixel infrared detector, 25mm focal length lens, ≤25mK thermal sensitivity, and laser range finding, the UTX325MR provides detailed thermal imaging and precise distance information for demanding outdoor and professional applications.

With a narrow 10.5° × 7.9° field of view, 50Hz refresh rate, manual focus, and a 0.39-inch OLED display, the UTX325MR is optimized for observing distant subjects and identifying thermal signatures with clarity. Its Hot Trace function helps locate hot objects, while Wi-Fi live streaming allows compatible devices to view thermal imagery remotely.

The rugged IP67-rated construction and 2-metre drop resistance make the UTX325MR suitable for demanding field environments. With more than 6 hours of continuous battery operation, it is designed for extended outdoor observation and professional inspection tasks.

What Is the Purpose of the UNI-T UTX325MR?

The primary purpose of the UNI-T UTX325MR thermal monocular is to provide long-distance thermal observation while also allowing users to measure the distance to a target using an integrated laser range finder.

Unlike conventional optical monoculars that rely primarily on visible light, thermal imaging detects infrared radiation and displays differences in thermal signatures. This makes the UTX325MR useful for observation in darkness, low-light conditions, and other challenging visibility environments.

The integrated laser range finder adds another important capability by providing direct distance measurement. This can help professionals make faster decisions when the distance to a person, animal, object, or inspection target is important.

How to Use the UNI-T UTX325MR Thermal Monocular?

1. Power on the monocular: Turn on the UTX325MR and allow the thermal imaging system to initialize.
2. Look through the OLED display: Position the monocular comfortably and use the integrated 0.39-inch OLED display for thermal observation.
3. Adjust the focus: Use the manual focus function to obtain a sharp image of the target at the required observation distance.
4. Choose the target: Identify the object, person, animal, or heat source that needs to be observed.
5. Use Hot Trace: Activate the Hot Trace function when you need assistance identifying or tracking areas with stronger thermal signatures.
6. Measure distance: Activate the laser range-finding function and aim the laser toward the intended target to obtain a distance measurement.
7. Monitor moving targets: The 50Hz refresh rate provides responsive thermal imagery for observing moving objects.
8. Use Wi-Fi live streaming: Connect a compatible device to the monocular's Wi-Fi function when remote viewing or live streaming is required.
9. Capture thermal images: Save images in PNG format for documentation and later review.
10. Recharge after use: Recharge the internal battery using the appropriate charging method after completing field operations.

Important: Laser range-finding equipment should always be operated responsibly. Never aim the laser toward aircraft, vehicle operators, or people's eyes. Follow the manufacturer's operating instructions and applicable local regulations.

Key Features of UNI-T UTX325MR

• 400 × 300 thermal resolution: Provides detailed thermal images for identifying heat signatures at long distances.
• 25mm long-range lens: The 25mm focal length is optimized for long-distance thermal observation and target detection.
• ≤25mK thermal sensitivity: Provides high sensitivity for detecting relatively small differences in thermal radiation.
• Laser range finding: Provides direct distance measurement to help users determine target distance quickly.
• 10.5° × 7.9° field of view: The focused field of view supports precise scanning and long-distance target observation.
• 50Hz refresh rate: Provides smooth and responsive thermal imagery when observing moving targets.
• 0.39-inch OLED display: Provides a high-resolution 1024 × 768 viewing display for thermal observation.
• Manual focus: Allows the user to adjust image sharpness for different target distances.
• Hot Trace: Helps identify and follow areas with stronger thermal signatures.
• Wi-Fi live streaming: Enables compatible devices to receive live thermal imaging for remote viewing.
• PNG image storage: Allows thermal images to be saved for documentation and analysis.
• 6+ hours battery life: Supports extended continuous use during outdoor and professional operations.
• IP67 protection: Provides protection against dust and water ingress for demanding field environments.
• 2-metre drop resistance: Designed to withstand accidental drops of up to 2 metres under the specified testing conditions.
• Portable monocular design: Combines thermal observation and laser distance measurement in a compact field device.

Why Choose the UNI-T UTX325MR?

The UNI-T UTX325MR is a strong choice for professionals who need both long-range thermal imaging and accurate distance measurement in a single portable device. The 25mm lens provides a focused viewing experience for distant targets, while the 400 × 300 infrared resolution delivers detailed thermal information.

Its ≤25mK thermal sensitivity helps identify subtle thermal differences, while the 50Hz refresh rate provides responsive imaging when observing moving subjects. The integrated laser range finder further improves situational awareness by providing direct distance information.

For demanding field environments, the IP67 construction and 2-metre drop resistance provide additional durability. Wi-Fi live streaming, Hot Trace, image capture, and more than 6 hours of battery operation further increase its usefulness for professional outdoor operations.

Who Should Buy the UNI-T UTX325MR?

The UNI-T UTX325MR is designed for professional users who require long-distance thermal observation, heat detection, and laser distance measurement.

• Search and rescue professionals
• Wildlife monitoring teams
• Outdoor observation professionals
• Security and perimeter monitoring teams
• Law enforcement professionals
• Industrial inspection technicians
• Infrastructure inspection teams
• Utility inspection professionals
• Field service technicians
• Navigation and outdoor operations teams
• Professional thermal imaging users
• Researchers conducting wildlife and environmental observation

Where Is the UNI-T UTX325MR Used?

• Search and rescue: Assist teams in locating heat signatures and estimating the distance to potential targets in challenging visibility conditions.
• Wildlife monitoring: Observe animals from a distance using thermal signatures while using laser range finding to estimate target distance.
• Perimeter security: Support long-distance thermal observation and monitoring of restricted areas.
• Outdoor observation: Provide thermal visibility during nighttime and low-light outdoor activities.
• Industrial inspection: Help identify abnormal heat signatures on equipment and components where long-distance observation is required.
• Utility inspection: Support observation of suitable electrical and infrastructure assets where thermal detection can assist inspection.
• Field operations: Provide portable thermal observation and distance measurement for professional teams working outdoors.
• Navigation support: Assist with identifying distant heat-producing objects and estimating their distance.
• Environmental observation: Support remote observation of wildlife and other heat-emitting subjects.

Frequently Asked Questions About UNI-T UTX325MR
