BRAND : PIONEER
ITEM NO.: YW5-47
ORIGIN : CHINA
MACHINENO.: 4C
VOLTAGE : 380V
FLOW RATE : 3 M³/H
FULL PRESSURE : 2900 PA
MOTOR POWER KW : 5.5 HP - 4 KW
SPEED : 2800 RPM
CERTIFICATION : ROHS, UR, ISO, CE, CCC
INSULATION LEVEL : E
TRANSPORT PACKAGE : WOODEN PACKING
USAGE : CONSTRUCTION, UNDERGROUND GARAGES, SHOPPING MALLS, MINES, TUNNELS, CHEMICAL INDUSTRY, POWER PLANTS, BUILDING MATERIALS, METALLURGY AND OTHER INDUSTRIES
APR. PACKAGE SIZE : 100X100X120CM
APR. PACKAGE GROSS WEIGHT : 200 KG
. THE FAN BLADES ARE MADE OF CARBON STEEL, ALUMINUM ALLOY, STAINLESS STEEL, CARBON FIBER, AND OTHER MATERIALS
. THE BLADE ANGLE IS ADJUSTABLE
. THE FAN CAN BE EQUIPPED WITH A SOLID BASE
. BEAUTIFUL APPEARANCE DESIGN, STABLE PERFORMANCE, AND LONG SERVICE LIFE
| Item Code | CHIPIFYW547-5.5 |
|---|---|
| Barcode | 6291116312604 |
| Brand | PIONEER |
The PIONEER YW5-47 Centrifugal Fan is a heavy-duty industrial fan blower designed to provide reliable air movement and high-pressure ventilation in demanding industrial and commercial environments. With a 5.5HP (4KW) motor, 2800 RPM operating speed, and 2900 Pa full pressure, it is suitable for construction sites, underground garages, tunnels, mines, shopping malls, chemical industries, power plants, and other large-scale applications.
Install the fan on a stable and suitable surface or use the optional solid base for secure positioning. Connect the fan to a compatible 380V power supply through the appropriate electrical protection and control equipment. Position the air inlet and outlet according to the required ventilation direction, then start the fan and adjust the airflow according to the application requirements.
The adjustable blade angle allows the airflow characteristics to be optimized for different ventilation requirements. Before operation, ensure that the fan, electrical connections, blades, and surrounding area are safe and free from obstructions.
The main purpose of the PIONEER YW5-47 is to provide industrial ventilation, air circulation, exhaust, and high-pressure air movement. It is designed for environments where dependable airflow and robust construction are required, including underground facilities, tunnels, mines, industrial plants, and large commercial buildings.
The PIONEER YW5-47 is a practical choice when a project requires a robust industrial blower capable of handling demanding ventilation conditions. Its high motor power, high-pressure performance, adjustable blade design, and durable construction make it suitable for a wide range of industrial and commercial ventilation applications.
Its adjustable blade angle provides additional flexibility when configuring the fan for different airflow requirements, while the optional solid base can provide additional installation stability.
The PIONEER YW5-47 is suitable for contractors, industrial maintenance teams, facility managers, construction companies, ventilation specialists, workshops, factories, mining operations, and businesses requiring high-performance industrial air movement equipment.
The PIONEER YW5-47 is equipped with a 5.5HP (4KW) motor.
The fan is designed for a 380V power supply.
The PIONEER YW5-47 operates at approximately 2800 RPM.
The specified full pressure is 2900 Pa.
Yes. The fan blade angle is adjustable, allowing the fan to be configured according to the required airflow application.
Yes. The PIONEER YW5-47 can be equipped with an optional solid base for improved installation stability.
It can be used in construction, underground garages, shopping malls, mines, tunnels, chemical industries, power plants, building material facilities, metallurgy, and other industrial applications.
The fan blades can be made from materials including carbon steel, aluminum alloy, stainless steel, and carbon fiber, depending on the required configuration.
The listed certifications include RoHS, UR, ISO, CE, and CCC.
