BRAND : MEGA
ITEM NO.: T1.5H
ORIGIN : SPAIN
COLOR : RED
LIFTING CAPACITY : 1.5 TON
DIMENSIONS :
A - 110 MM
B - 665 MM
C - 165 MM
D - 775 MM
E - 1250 MM
F - 2180 MM
G - 360 MM
H - 360 MM
WEIGHT : 60.5 KG
. THE INSIDE WHEEL ON TI.5H MODELS ALLOWS FOR EXCELLENT MANOEUVRABILITY.
. FOOT PEDAL FOR QUICK APPROACH OF LIFTING SADDLE TO LOAD
. SAFETY LOCK TO AVOID INVOLUNTARY ACTIONS
. THE MODELS UNDER 6T ARE FITTED WITH POLYAMIDE WHEELS. THESE WHEELS WILL NOT DAMAGE GARAGE FLOORS, DO NOT RUST AND ARE QUIET IN OPERATION.
. OPTIMUM USE AND DISTRIBUTION OF MATERIAL THANKS TO THE REAR SIDE OPENINGS AND FRONT SIDE REINFORCEMENTS. LIGHTER YET STRONGER
. CAREFUL DESIGN AND EXCELLENT PRODUCTION QUALITY THANKS TO THE USE OF STATE-OF-THE-ART TECHNOLOGIES
. EASILY ACCESSIBLE THANKS TO A VERY LOW CHASSIS ON 2-TON MODELS (135 MM AT THEIR HIGHEST POINT)
. GREAT LIFTING SPEED. LIFT 20% FASTER THAN THEIR PREVIOUS GENERATION IN TERMS OF APPROACH AND WHEN LOADED.
. OVERLOAD SAFETY VALVE. LCS
. "DEAD MAN'S" OPERATION (STOPS OPERATION IF THE USER UNINTENTIONALLY LOSES CONTROL).
THE ERGONOMIC HANDLE WITH RUBBER GRIP ALLOWS FOR EASIER HANDLING FROM ANY POSITION.
POSITION 1: TO REDUCE THE EFFORT REQUIRED WHEN PUMPING.
POSITION 2: TO ALLOW A LONGER PUMPING MOVEMENT.
| Item Code | MEGAT1.5H |
|---|---|
| Barcode | 6295123250546 |
| Brand | MEGA-JACK |
The MEGA T1.5H Hydraulic Trolley Jack is a premium heavy-duty lifting solution engineered in Spain for professional automotive, industrial, and maintenance applications. Designed with superior lifting performance, enhanced safety features, and exceptional maneuverability, this 1.5-ton hydraulic floor jack is ideal for lifting cars, vans, light commercial vehicles, and workshop equipment. Featuring polyamide wheels, a foot-operated quick-lift pedal, overload safety valve, and "Dead Man's" safety operation, the T1.5H delivers reliable performance and operator protection in demanding work environments.
Position the trolley jack on a flat, stable surface and roll it beneath the designated lifting point of the vehicle or equipment. Use the foot pedal to quickly bring the lifting saddle into contact with the load. Operate the ergonomic handle to pump the hydraulic system and raise the load smoothly. Once the desired lifting height is reached, support the load using approved jack stands before performing any work. After completing the task, carefully release the hydraulic pressure to lower the load in a controlled manner.
The MEGA T1.5H is designed to safely lift vehicles and heavy equipment for maintenance, repair, inspection, tire replacement, and service operations. It provides stable lifting performance while reducing operator effort and improving workplace efficiency.
The MEGA T1.5H combines advanced Spanish engineering, operator safety, and high-performance hydraulic lifting technology. Its quick-lift foot pedal reduces setup time, while the overload safety valve and Dead Man's operation system provide enhanced workplace safety. The durable polyamide wheels offer excellent mobility without damaging workshop floors, making this trolley jack a dependable choice for professional users.
The MEGA T1.5H has a maximum lifting capacity of 1.5 tons, making it suitable for many automotive and workshop lifting applications.
The foot pedal allows rapid positioning of the lifting saddle, reducing setup time and improving lifting efficiency.
Polyamide wheels are durable, quiet, rust-resistant, and help protect workshop floors from damage during movement.
The overload safety valve helps prevent lifting loads beyond the jack's rated capacity, enhancing operator safety and protecting the hydraulic system.
The Dead Man's principle automatically stops operation if the user unintentionally loses control, providing an additional level of safety during lifting tasks.
