DECA PLASMA CUTTER 350 V HYPERPAC 50E 4.5 BAR 114300 | 5KW CONSUMPTION | PRELIMINARY ARC | PROTECTION AGAINST ELECTRIC SHOCK | MADE IN ITALY

BRAND : DECA
ITEM NO.: HYPERPAC 50E
ORIGIN : ITALY
INPUT VOLTAGE : ΦXV 1X230
FUSE : A 20
POWER CONSUMPTION : KW 5
POWER FACTOR : COS Φ 0.75
EFFICIENCY : Η 0.8
OPEN CIRCUIT VOLTAGE (OCV) : V 350
WELDING CURRENT ADJUSTMENT LIMITS : A 10 ÷ 40
MAX. METAL THICKNESS : MM 12
AIR PRESSURE : BAR 4.5
AIR CONSUMPTION : L/MIN 120
DIMENSIONS : MM 400 X 150 X 310
WEIGHT : 14 KG

. SMOOTH AND UNIFORM CUTTING OF ALL TYPES OF METAL: STEEL, STAINLESS STEEL, ALUMINUM, COPPER, ETC.
. POSSIBILITY OF CUTTING SHEET METAL WITHOUT DAMAGING THE UNDERLYING SURFACES
. EFFICIENT CUTTING OF METAL WITH MINIMAL DAMAGE TO THE EDGE OVERLOAD PROTECTION SYSTEM
. PRELIMINARY ARC
. AIR PRESSURE ADJUSTMENT WITHOUT ARC INTERRUPTION
. PROTECTION AGAINST ELECTRIC SHOCK
. PROTECTION AGAINST LOW/HIGH SUPPLY VOLTAGE
. SMALL DIMENSIONS OF THE DEVICE - EASE AND CONVENIENCE IN OPERATION.

AIR PLASMA CUTTING MACHINE. DESIGNED FOR FAST AND EFFICIENT CUTTING OF METAL WITH A MAXIMUM PART THICKNESS OF 12 MM. A JET OF COMPRESSED AIR IS USED TO GENERATE PLASMA. THE USE OF INVERTER TECHNOLOGY ALLOWS TO REDUCE THE DIMENSIONS AND WEIGHT OF POWER TRANSFORMERS, WHICH IN TURN REDUCES THE DIMENSIONS AND WEIGHT OF ALL WELDING EQUIPMENT. THE QUALITY OF WELDING OPERATIONS USING INVERTER TECHNOLOGY IS HIGHER THAN WITH TRADITIONAL TECHNOLOGIES, PRODUCTIVITY INCREASES AND CONTROL OVER THE ELECTRIC ARC IS IMPROVED.
