BRAND : ALFRA
ITEM NO.: 0600290
ORIGIN : GERMANY
TYPE : FLAT CUT
SIZE : Ø29 MM (1-1/8")
CUTTING DEPTH :
CONSTRUC STEEL : MAX 4 MM
CHROME NICKEL SHEETS : BIS 2MM
TEETH : 5 TUNGSTEN CARBIDE TOOTH
MATERIAL : HARDENED STEEL
USAGE : PLASTICS, PVC, ALUMINIUM, ZINC, GYPSUM PLASTER BOARDS AND LIGHTWEIGHT BUILDING BOARDS, AS WELL AS ASBESTOS
. HIGH CONCENTRIC RUNNING EXACTNESS THROUGH SOLID CONSTRUCTION
. CAD-OPTIMIZED CUTTING ANGLES WITH SPECIALLY GROUND SECTION ENSURES HIGH CUTTING CAPACITY AND LONG TOOL LIFE.
. QUICK REMOVAL OF DRILLED CORE THROUGH EJECTOR SPRING FOR ALL HOLE SAWS
UP TO 150 MM (5-29/32") Ø
. CARBIDE TIPPING ENABLES REPEATED RE-GRINDING.
. ALFRA HOLE SAWS ARE REPAIRABLE. IN THE EVENT OF A TOOTH BREAKING, IT CAN EASILY BE REPLACED AND RESHARPENED.
. EXCHANGEABLE CENTER PIN.
. USE OF MT TOOL HOLDERS FROM Ø 31 MM (1-7/32").
. FOR USE ON HAND DRILLING MACHINES (RECOMMENDED UP TO MAX. Ø 40 MM; 1-9/16") OR STATIONARY MACHINES.
THE APPLICATION AREA OF TCT HOLE SAWS DIFFERS FROM HSS-BI-METAL HOLE SAWS. WITH ALFRA TCT HOLE SAWS, SUITABLE TO ECONOMICALLY PROCESS STAINLESS STEEL UP TO 2 MM (1/16"), UNALLOYED STEELS UP TO 4 MM (3/16"), PLASTICS, PVC, ALUMINIUM, ZINC, GYPSUM PLASTER BOARDS AND LIGHTWEIGHT BUILDING BOARDS, AS WELL AS ASBESTOS. DO NOT USE AUTOMATIC FEED, WHEN WORKING WITH PILLAR DRILLING MACHINES. FOR THE USE ON PORTABLE- AND PILLAR DRILLING MACHINES.DO NOT USE AUTOMATIC FEED, WHEN WORKING WITH PILLAR DRILLING MACHINES.
ANOTHER SPECIAL TECHNICAL FEATURE:
FROM Ø 15.2 MM (3/16") TO 30.0 MM (1-1/8"), THE HOLE SAW IS MADE OF ONE PIECE. FROM Ø 31.0 MM (1-3/16") WE USE SPECIALLY HARDENED TOOL HOLDERS TO COMPENSATE FOR THE TORSIONAL POWER IN CASE OF HEAVY OPERATION, WHICH AVOIDS EARLY SHEARING OFF OF THE TOOL HOLDER SHANK.
IN TERMS OF CONSTRUCTION NOT COMPARABLE WITH ANY OTHER MAKE.
| Item Code | ALFRATCTHS29 |
|---|---|
| Barcode | 111000005783 |
| Brand | ALFRA |
