BRAND : NAMSON
ITEM NO.: EH1000KG
MODEL : FIXED TYPE
POWR SOURCE : ELECTRIC
LIFTING CAPACITY (KG) : 500/1000
LIFTING HEIGHT : 12/6
LIFTING SPEED : 10/5
CABLE LONG (M) : 12
WIRE ROPE SIZE (MM) : 6
RATED VOLT (V) : 110/220V/50 HZ
FORCE :
INPUT POWER : 1600W
INSULATION RANK : B
PROTECTION RANK : IP40
WORK QUITA : 20%10 MIN
THE NAMSON MINI ELECTRIC WIRE ROPE HOIST, FIXED TYPE, IS A ROBUST AND EFFICIENT LIFTING DEVICE DESIGNED FOR HANDLING HEAVY LOADS WITH EASE. WITH A LIFTING CAPACITY OF UP TO 1000 KG, IT OFFERS FLEXIBLE OPERATION, ALLOWING FOR EITHER SINGLE-LINE LIFTING AT 500 KG WITH A HEIGHT OF 12 METERS OR DOUBLE-LINE LIFTING AT 1000 KG WITH A HEIGHT OF 6 METERS. IT OPERATES AT A LIFTING SPEED OF 10 METERS PER MINUTE FOR SINGLE-LINE AND 5 METERS PER MINUTE FOR DOUBLE-LINE CONFIGURATIONS, POWERED BY A 1600W ELECTRIC MOTOR.
THIS HOIST IS DESIGNED WITH SAFETY AND DURABILITY IN MIND, FEATURING A 6MM WIRE ROPE AND A 12-METER LONG CABLE. IT OPERATES ON A RATED VOLTAGE OF 110/220V AT 50 HZ, PROVIDING RELIABLE PERFORMANCE ACROSS VARIOUS SETTINGS. THE HOIST'S INSULATION RANK IS B, AND IT HAS A PROTECTION RATING OF IP40, ENSURING IT IS WELL-PROTECTED AGAINST DUST AND OTHER PARTICLES. WITH A DUTY CYCLE OF 20% FOR 10 MINUTES, THE NAMSON MINI ELECTRIC WIRE ROPE HOIST IS IDEAL FOR BOTH LIGHT AND HEAVY-DUTY APPLICATIONS, MAKING IT A VERSATILE TOOL FOR WORKSHOPS, CONSTRUCTION SITES, AND INDUSTRIAL ENVIRONMENTS.
ITEM NO.: EH1000KG
MODEL : FIXED TYPE
POWR SOURCE : ELECTRIC
LIFTING CAPACITY (KG) : 500/1000
LIFTING HEIGHT : 12/6
LIFTING SPEED : 10/5
CABLE LONG (M) : 12
WIRE ROPE SIZE (MM) : 6
RATED VOLT (V) : 110/220V/50 HZ
FORCE :
INPUT POWER : 1600W
INSULATION RANK : B
PROTECTION RANK : IP40
WORK QUITA : 20%10 MIN
THE NAMSON MINI ELECTRIC WIRE ROPE HOIST, FIXED TYPE, IS A ROBUST AND EFFICIENT LIFTING DEVICE DESIGNED FOR HANDLING HEAVY LOADS WITH EASE. WITH A LIFTING CAPACITY OF UP TO 1000 KG, IT OFFERS FLEXIBLE OPERATION, ALLOWING FOR EITHER SINGLE-LINE LIFTING AT 500 KG WITH A HEIGHT OF 12 METERS OR DOUBLE-LINE LIFTING AT 1000 KG WITH A HEIGHT OF 6 METERS. IT OPERATES AT A LIFTING SPEED OF 10 METERS PER MINUTE FOR SINGLE-LINE AND 5 METERS PER MINUTE FOR DOUBLE-LINE CONFIGURATIONS, POWERED BY A 1600W ELECTRIC MOTOR.
THIS HOIST IS DESIGNED WITH SAFETY AND DURABILITY IN MIND, FEATURING A 6MM WIRE ROPE AND A 12-METER LONG CABLE. IT OPERATES ON A RATED VOLTAGE OF 110/220V AT 50 HZ, PROVIDING RELIABLE PERFORMANCE ACROSS VARIOUS SETTINGS. THE HOIST'S INSULATION RANK IS B, AND IT HAS A PROTECTION RATING OF IP40, ENSURING IT IS WELL-PROTECTED AGAINST DUST AND OTHER PARTICLES. WITH A DUTY CYCLE OF 20% FOR 10 MINUTES, THE NAMSON MINI ELECTRIC WIRE ROPE HOIST IS IDEAL FOR BOTH LIGHT AND HEAVY-DUTY APPLICATIONS, MAKING IT A VERSATILE TOOL FOR WORKSHOPS, CONSTRUCTION SITES, AND INDUSTRIAL ENVIRONMENTS.
