BRAND : PIONEER
ITEM NO.: PHC-2090
ORIGIN : CHINA
AIR INLET PRESSURE : 6～8BAR/ 87～116PSI
EJECTION PRESSURE : 0.7～1 BAR/ 10～14PSI
AIR CONSUMPTION : 150L/MIN
VACUUM DEGREE : 0～-1 BAR /-14PSI
TANK CAPACITY : 65L
CYLINDER CAPACITY : 9L
WORKING TEMPERATURE : 40～60℃
PACKAGE : CYLINDER/BOX - OIL TANK/BOX
CARTON SIZE : 255X255X540MM/470X400X940MM
SUCTION PROBES：
Φ5XL800MM,(CU,1 PCS) SUCTION SPEED : 1.9 L/MIN.
Φ6XL800MM,(CU,1 PCS) SUCTION SPEED : 3.2 L/MIN.
Φ6XL700MM,(PVC,1PCS) : SUCTION SPEED 4.2 L/MIN.
Φ8XL700MM,(PVC,1PCS) : SUCTION SPEED 6.2 L/MIN.
Φ6XL800MM,(PVC,1PCS) : SUCTION SPEED 3.7 L/MIN.
Φ8XL800MM,(PVC,1PCS) : SUCTION SPEED 5.2 L/MIN.
1.FAST VACCUM SPEED, CAPABLE OF HIGH NEGATIVE PRESSURE, MULTI-PURPOSE EQUIPMENT.
2.HIGH QUALITY CYLINDER, HIGHER INTENSITY, HIGH GRADE OF TRANSPARENCY AS WELL AS HIGH TEMPERATURE RESISTANCE (ABLE TO WITHSTAND 80℃ & NEGATIVE PRESSURE WITHOUT DEFORMING). TRANSPARENT CYLINDER ALLOWS OIL OBSERVATION AND MEASUREMENT.
3.USE COMPRESSED AIR AS POWER SOURCE; GUARANTEE THE SAFETY IN USE, ECO FRIENDLY AND LOW POWER CONSUMPTION.
4.VACUUM CYLINDER AND OIL TANK AT A SAME TIME, INCREASE OIL EXTRACTION SPEED.
5.DIFFERENT DIAMETER OF OIL SUCTION PROBES TO MEET THE NEED OF DIFFERENT TYPE OF CARS.
6.HEIGHT ADJUSTABLE OIL TRAY LIFT, CAN BE FIX TO DESIRABLE HEIGHT.
7.CAN BE USED WITH OTHER MECHANICAL ENGINE OIL, LUBRICANTS AS WELL AS TEMPORARY STORAGE. BRAKE FLUID, GASOLINE, DIESEL AND OTHER LIQUID CONTAINS METHANOL AND KETONES OR FLAMMABLE IS STRICTLY PROHIBITED.
